Ubiquiti  |  SKU: UACC-ETH-SP-PANEL-24

Ubiquiti Ethernet Surge Protection Panel UACC-ETH-SP-PANEL-24

$389.00

Delivery and Shipping

The cost of shipping your order is determined at checkout, factoring in the speed of delivery you select, as well as the size and weight of the items you've chosen. Please note, our daily cutoff time for same day shipping is 12PM Eastern Standard Time. If you need rush or same-day processing after these cutoff times, please contact us as same-day shipping may still be possible. You can reach us by phone at 781-272-0967 or by email at frontdesk@c3aero.com

Please see our Shipping Policy for more information.

Rack-mount indoor panel supports up to 10 GbE, PoE++, and 20kA surge discharge per port.

Fits in a 1U rack

Dimensions
442.4 x 134 x 43.7 mm (17.4 x 5.3 x 1.7")
Weight
2 kg (4.4 lb)
Enclosure Material
SGCC steel

Networking Interface
(48) RJ45 female connectors
DC Spark-Over Voltage
90V @ 100V/s
Max. Impulse Spark-Over Voltage
600V @ 1kV/µs
Discharge Current
20kA
Insulation
Max. Resistance: 1G ohm @ 50V
Max. Capacitance
1.0 pF @ 1 MHz
Data Line Protection
Up to 10 Gbps
PoE Support
ESD/EMP Protection
Absorbing transient current with response to surge voltage from 100V/s to 1kV/µs
Ambient Operating Temperature
-40° to +80° C (-40° to 176° F)
Ambient Operating Humidity
10 to 90% noncondensing



Payment & Security

Payment methods

  • Amazon
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • Shop Pay
  • Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Ubiquiti

Ubiquiti Ethernet Surge Protection Panel UACC-ETH-SP-PANEL-24

$389.00

Rack-mount indoor panel supports up to 10 GbE, PoE++, and 20kA surge discharge per port.

Fits in a 1U rack

Dimensions
442.4 x 134 x 43.7 mm (17.4 x 5.3 x 1.7")
Weight
2 kg (4.4 lb)
Enclosure Material
SGCC steel

Networking Interface
(48) RJ45 female connectors
DC Spark-Over Voltage
90V @ 100V/s
Max. Impulse Spark-Over Voltage
600V @ 1kV/µs
Discharge Current
20kA
Insulation
Max. Resistance: 1G ohm @ 50V
Max. Capacitance
1.0 pF @ 1 MHz
Data Line Protection
Up to 10 Gbps
PoE Support
ESD/EMP Protection
Absorbing transient current with response to surge voltage from 100V/s to 1kV/µs
Ambient Operating Temperature
-40° to +80° C (-40° to 176° F)
Ambient Operating Humidity
10 to 90% noncondensing
