The Ubiquiti UniFi 10G Bidirectional Single-Mode Optical Module (20-pack) UACC-OM-SM-10G-S-20 is an SFP+ transceiver that supports 10G connections up to 10 km using single-mode fiber with a simplex LC UPC connector.
Max data rate: 10 Gbps
Compatible with SFP+ and SFP interfaces
Simplex LC UPC connector
Supports single-mode fiber connections up to 10 km*
*Fiber cable is not included.
Technical Specifications
| Supported media | Single-mode fiber |
| Connector type | (1) LC |
| BiDi | Yes |
| TX wavelength* | Blue latch: 1270 nm Red latch: 1330 nm *Must be used in pairs (blue latch and red latch). |
| RX wavelength* | Blue latch: 1330 nm Red latch: 1270 nm *Must be used in pairs (blue latch and red latch). |
| Data rate | 10 Gbps |
| Max. power consumption | 1W |
| Cable distance | 10 km |
| Ambient operating temperature | 0 to 70° C (32 to 158° F) |
| Pack options | 2-pack, 20-pack |
| WARNING | CLASS 1 LASER PRODUCT, IEC/EN 60825-1:2014 – Do not look into the ends of the fiber optic cable or SFP module while converters are powered. |
