The Ubiquiti UniFi G3 Intercom UA-G3-INTERCOM is an indoor/outdoor intercom terminal for managing residential and commercial building entry requests with Touch Pass support.
Technical Specifications
| Dimensions | 324.8 x 113.7 x 28.3 mm (12.8 x 4.5 x 1.1") |
| Integrated Camera | ✓ |
| NFC Card & Keyfob Access | ✓ |
| PIN Access | ✓ |
| Touch Pass | ✓ |
| Mobile Unlock | ✓ |
| Two-Way Intercom & Doorbell Access | ✓ |
| Weatherproofing | IP65 |
| Mechanical | |
| Weight (Device) | 965 g (2.1 lb) |
| Weight (Bracket) | 445 g (1 lb) |
| Enclosure Material | Aluminum alloy, UV-stabilized polycarbonate, glass |
| Mount Material | Powder-coated stainless steel |
| Mounting | Wall mount, adapter to gooseneck pedestal (Included) |
| Optional Mounting | Surface angle, flush mount, sunshield kit (Optional) |
| Hardware | |
| Indoor and Outdoor Use | Yes |
| Ambient Operating Temperature (Device) | -30 to 60° C (-22 to 140° F) |
| Ambient Operating Temperature (Display) | -25 to 60° C (-13 to 140° F) |
| Ambient Operating Humidity | 5 to 90% noncondensing |
| Networking Interface | (1) GbE RJ45 port |
| Connectivity | BLE 4.2, NFC |
| Power Method | PoE, UL 294 Power-limited Class 2 PSU, UL 60950-1/62368-1 LPS/PS2 PSU |
| Max. Power Consumption | 13W |
| Supported Voltage Range | 48V DC |
| Sensors | Proximity sensor, ALS sensor |
| Display | |
| Size | 177 mm (7") diagonal |
| Touch Screen Technology | Capacitive multi-touch |
| Display Luminance | Max. 1000 nits (Typical) |
| Screen Orientation | Portrait |
| Resolution | 1024 x 600 px |
| Audio & Communication | |
| Microphone | ✓ |
| Speaker | ✓ |
| NFC | |
| Frequency | 13.56 MHz |
| Read Range | < 30 mm (1.18'') |
| Technology | ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340), MIFARE Classic / MIFARE DESFIRE, Sony FeliCa™ (ID only), NFC Forum tags T1T, T2T, T3T, T4T and T5T, ECP 2.0 |
| LEDs & Buttons | |
| LEDs | Amber Learn More |
| Buttons | (1) Factory-reset |
| PoE Cabling Requirements | |
| Minimum Category | Cat 5e cabling recommended |
| Minimum Conductor Gauge | 26 AWG (0.13 mm²) for patch cords, 24 AWG (0.21 mm²) for horizontal/riser cable |
| UL 294 Compliance | |
| Destructive Attack | Level I |
| Line Security | Level I |
| Endurance | Level I |
| Standby Power | Level I |
| UL 294 Statement | Compliance with IEEE 802.3 specifications was not verified as part of UL 294. Equipment intended to comply with ANSI/NFPA 70, Article 725.121 |
| Certifications & Standards | |
| CAN/ULC-60839-11-1 Grade | Grade I |
| Certifications | CE, FCC, IC, UL 294, CAN/ULC-60839-11-1 |
| Document Number | UA-G3-Intercom, V01 |
| Software | |
| Management Application | Access |
| Software Information | Version details can be checked at https://unifi.ui.com |
