Ubiquiti  |  SKU: USW-PRO-XG-AGGREGATION

Ubiquiti UniFi Pro XG Aggregation USW-PRO-XG-AGGREGATION

$2,499.00

Delivery and Shipping

The cost of shipping your order is determined at checkout, factoring in the speed of delivery you select, as well as the size and weight of the items you've chosen. Please note, our daily cutoff time for same day shipping is 12PM Eastern Standard Time. If you need rush or same-day processing after these cutoff times, please contact us as same-day shipping may still be possible. You can reach us by phone at 781-272-0967 or by email at frontdesk@c3aero.com

Please see our Shipping Policy for more information.

Please contact us for availability.

The Ubiquiti UniFi Pro XG Aggregation USW-PRO-XG-AGGREGATION is a professional-grade 32-port, Layer 3 Etherlighting™ switch for high-capacity 25G SFP28 connections.

Technical Specifications

Category Specification
Overview
Dimensions 442.4 x 43.7 x 480 mm (17.4 x 1.7 x 18.9")
Port Layout 25G SFP28: 32 ports (25G/10G/1G)
Redundancy DC Power Backup
Layer 3
Form Factor Rack Mount (1U)
Etherlighting™
Performance
Switching Capacity 1.6 Tbps
Total Non-Blocking Throughput 800 Gbps
Forwarding Rate 1.2 Bpps
Supported VLANs 1,000
MAC Address Table Size 32,000
L3 Table Size
• ARP Entries 128,000
• IPv4 Routes 256,000
Packet Buffer Size 8 MB
Layer 3 Features
DHCP Server (Local Networks)
DHCP Relay
Inter-VLAN Routing
Static Routing
Layer 2 Features
LACP Port Aggregation
STP & RSTP
Advanced IGMP Configuration ✓ (Querier, Fast Leave, Router Port)
IGMP Snooping
802.1X Control
MAC-Based ACLs & Isolation
DHCP Snooping & Guarding
Egress Rate Limit
Flow Control
Storm Control
Multicast & Broadcast Limiting
MAC Address Blocking
IP-Based ACLs & Isolation
MAC-Based Port Restriction
Port Isolation
Port Mirroring
Jumbo Frames
LLDP-MED
Voice VLAN
Loop Protection
Hardware
Max. Power Consumption 200W
Power Method (1) Universal input, 100–240V AC, 50/60 Hz (1) USP RPS DC input
Power Input Method AC input
Power Supply AC/DC, internal, 200W
Supported Voltage Range 100–240V AC
Management Ethernet
AR
Weight 7 kg (19.8 lb)
Enclosure Material SGCC steel
Mount Material SGCC steel
Supported Rack Depth 482.6 mm (19") four-post racks Posts: 600–1,066 mm (23.6–42")
LCM Display 1.3" touchscreen
ESD/EMP Protection Air: ±12kV, contact: ±8kV
Ambient Operating Temperature -5 to 40°C (23 to 104°F)
Ambient Operating Humidity 10 to 90% noncondensing
Etherlighting™ SFP28
LEDs RPS: ✓
NDAA Compliant
Certifications CE, FCC, IC
