Ubiquiti  |  SKU: USW-WAN-RJ45

Ubiquiti UniFi WAN Switch RJ45 USW-WAN-RJ45

$249.00

Delivery and Shipping

The cost of shipping your order is determined at checkout, factoring in the speed of delivery you select, as well as the size and weight of the items you've chosen. Please note, our daily cutoff time for same day shipping is 12PM Eastern Standard Time. If you need rush or same-day processing after these cutoff times, please contact us as same-day shipping may still be possible. You can reach us by phone at 781-272-0967 or by email at frontdesk@c3aero.com

Please see our Shipping Policy for more information.

The Ubiquiti UniFi WAN Switch RJ45 USW-WAN-RJ45 is a 10 GbE WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP.

Note. Use an additional USW-WAN-RJ45 switch for deployments with multiple ISPs.

Technical Specifications

Category Specification
Overview
Dimensions 442.4 x 120 x 43.7 mm (17.4 x 4.72 x 1.7")
Port Layout 1 GbE RJ45: 1 port (1G/100M/10M) 10 GbE RJ45: 3 ports (10G/5G/2.5G/1G/100M)
Redundancy (2) AC inputs
Form Factor Rack mount (1U)
Performance
Switching Capacity 20 Gbps
Total Non-Blocking Throughput 10 Gbps
Forwarding Rate 15 Mpps
Hardware
Max. Power Consumption 18W
Power Method (2) Universal input, 100–240V AC, 50/60 Hz
Power Input Method AC input
Power Supply (2) AC/DC, internal, 36W
Supported Voltage Range 100–240V AC
Management Ethernet
Weight Without mounting brackets: 2.3 kg (5.1 lb) With mounting brackets: 2.4 kg (5.3 lb)
Enclosure Material SGCC steel
Mount Material SGCC steel
ESD/EMP Protection Air: ±16kV, contact: ±10kV
Ambient Operating Temperature -5 to 40°C (23 to 104°F)
Ambient Operating Humidity 10 to 90% noncondensing
LEDs Ethernet: ✓ System: ✓
Certifications CE, FCC, IC
NDAA Compliant
Software
Application Requirements UniFi Network Version 9.1.119 and later
