The Ubiquiti UniFi Ubiquiti UniFi WAN Switch usw-wan is a 10G SFP+ WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP.
Note. Use an additional USW-WAN switch for deployments with multiple ISPs.
Technical Specifications
| Category | Feature | Specification |
|---|---|---|
| Overview | Dimensions | 442.4 x 120 x 43.7 mm (17.4 x 4.72 x 1.7") |
| Port Layout – 1 GbE RJ45 | 1 (1G/100M/10M) | |
| Port Layout – 10G SFP+ | 3 (10G/1G) | |
| Redundancy | (2) AC inputs | |
| Form Factor | Rack mount (1U) | |
| Performance | Switching Capacity | 20 Gbps |
| Total Non-Blocking Throughput | 10 Gbps | |
| Forwarding Rate | 15 Mpps | |
| Hardware | Max. Power Consumption | 13W |
| Power Method | (2) Universal input, 100–240V AC, 50/60 Hz | |
| Power Input Method | AC input | |
| Power Supply | (2) AC/DC, internal, 36W | |
| Supported Voltage Range | 100–240V AC | |
| Management Ethernet | Yes | |
| Weight | 2.2 kg (4.85 lb) without brackets2.3 kg (5.1 lb) with brackets | |
| Enclosure Material | SGCC steel | |
| Mount Material | SGCC steel | |
| ESD/EMP Protection | Air: ±16kV, Contact: ±22kV | |
| Ambient Operating Temperature | -5 to 40° C (23 to 104° F) | |
| Ambient Operating Humidity | 10 to 90% noncondensing | |
| LEDs – Ethernet | ✓ | |
| LEDs – SFP+ | ✓ | |
| LEDs – System | ✓ | |
| Certifications | CE, FCC, IC | |
| NDAA Compliant | ✓ | |
| Software | Application Requirements | UniFi Network Version 9.1.119 and later |
